Ring Joint Gaskets


Ring Joint Gaskets

We have come up with the finest range of Ring Joint Gaskets for our clients. WFY RJ3200 is machined from solid metal in a variety of shapes and designed for high pressure, high temperature or highly corrosive applications by selecting the most suitable material and shape. Our Ring Joint Gasket is designed to withstand exceptionally high assembly loads over a small area, thus producing high seating stresses.

Ring Joint Gaskets are obtained by mechanical working from forged or laminated metals. These Ring Joint Gaskets are employed in the production and refining process of oil and chemical industries. These gaskets are designed in oval/octagonal shapes confirming to R, Bx and Rx series of API STD 6A.

Types
  • 3300 PL Plain type RJG
  • 3300 OV Oval type RJG
  • 3300 OC Octagonal type RJG
  • 3300 RX RX type RJG
  • 3300 BX BX type RJG
  • 3300 S Special type RJG

Applications
  • Steel
  • Mining
  • Petrochemical
  • Refining
  • Fertilizer industries


Specifications

Material Code Sample Hardness(HB) T
Soft Iron R23 SI 90 530
Carbon Steel R23 CS 120 530
304(L)/321/316(L) R23 S304 160 750
5Cr1/2Mo R23 F5 130 500
Copper for 640PL 50 400
Aluminium for 640PL 30 300

Dimensions

Standards for Ring Joints Gaskets used with flanges
RJG Style RJG standard Flange standard
R ASME B 16.20 API 6A ANSI B 16.5 ANSI B 16.47 Series A
RX ASME B 16.20 API 6A API 6B
BX API 6A API 6BX
